Audio: Realtek® Audio CODEC; High Definition Audio; 2/4/5.1/7.1-channel

BIOS: 1 x 256 Mbit flash; Use of licensed AMI UEFI BIOS; PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Chipset: Intel® B560 Express Chipset

Connectors: 1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 1 x CPU fan header; 3 x system fan headers; 1 x addressable LED strip header; 1 x RGB LED strip header; 6 x SATA 6Gb/s connectors; 2 x M.2 Socket 3 connectors; 1 x front panel he

CPU's supported: LGA1200 package: 11th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors; 10th Generation Intel® Core™ i9 processors / Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors/

Expansion Slots: 1 x PCI Express x16 slot, running at x16; (The PCIEX16 slot conforms to PCI Express 4.0 standard.)(Note); 2 x PCI Express x1 slots; (The PCIEX1 slot conforms to PCI Express 3.0 standard.)

Form Factor: Micro ATX Form Factor; 24.4cm x 24.4cm

Graphics: Integrated Graphics Processor-Intel® HD Graphics support: 1 x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz; * The DVI-D port does not support D-Sub connection by adapter.; 1 x DisplayPort, supporting a maximum resolution of 4096x230

I/O: 2 x USB 2.0/1.1 ports; 1 x PS/2 keyboard/mouse port; 1 x DVI-D port; 1 x DisplayPort; 1 x HDMI port; 3 x USB 3.2 Gen 1 ports; 1 x USB Type-C® port, with USB 3.2 Gen 1 support; 1 x RJ-45 port; 3 x audio jacks

LAN: Realtek® GbE LAN chip (1 Gbps/100 Mbps)

Memory type: 11th Generation Intel® Core™ i9/i7/i5 processors: Support for DDR4 5333(O.C.) / DDR4 5133(O.C.) / DDR4 5000(O.C.) / 4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866

OS: Support for Windows 10 64-bit

Storage: CPU: 1 x M.2 connector (Socket 3, M key, type 2260/2280/22110 PCIe 4.0 x4/x2 SSD support) (M2P_CPU)(Note); Chipset: 1 x M.2 connector (Socket 3, M key, type 2260/2280 SATA and PCIe 3.0 x4/ x2 SSD support) (M2A_SB); 6 x SATA 6Gb/s connectors; * Refer

Warranty: 36 Months

Марка: GIGABYTE

Чипсет: Intel B560
